The Kanomax Handheld Micromanometer – Model 6850 is a compact, high-precision instrument designed for professionals who require accurate airflow and pressure measurements in HVAC testing, adjusting, and balancing applications. Its ergonomic design and advanced features make it an essential tool for technicians performing duct traverses and other airflow assessments.
Accurate and Reliable Measurements
The Model 6850 offers high-resolution pressure measurements and calculates average airflow and volumetric flow rates when used with a pitot tube (sold separately). It measures airflow velocities ranging from 0.2 to 60 m/s with an accuracy of ±1.5% of reading at 10 m/s and a resolution of 0.01 m/s. For pressure measurements, it covers a range of -2500 to 2500 Pa with an accuracy of ±0.5% of reading ±1 Pa and a resolution of 0.1 Pa.
User-Friendly Design
Weighing only 360 grams (0.79 lbs) and measuring 85 x 200 x 40 mm, the 6850 is lightweight and portable, making it ideal for field use. An optional attachable strap allows the device to be hung from the user or a nearby fixture, facilitating hands-free operation during duct traverses.
Data Logging and Connectivity
The micromanometer features a USB interface for easy data transfer and can store up to 10,000 measurements, enabling comprehensive data logging for analysis and reporting.
More Information
Navigate the tab section below to see this product’s Features & Benefits, Specifications, Resources, and more.
- High resolution pressure measurement
- Average airflow measurement
- Airflow (volumetric flow) measurement capabilities
- Duct traverse-capable with pitot tube (sold separately)
- HVAC Testing, Adjusting, and Balancing
- Duct Traverse
| Measurement Specifications | ||
|---|---|---|
| Airflow | Range | 0.2 to 60 m/s |
| Accuracy | ±1.5% of reading (at 10 m/s) | |
| Resolution | 0.01 m/s | |
| Pressure | Range | -2500 to 2500 Pa |
| Accuracy | ±0.5% of reading ±1 Pa | |
| Resolution | 0.1 Pa | |
| General Specifications | ||
| Operating Temperature | 32 to 140°F (0 to 60°C) | |
| Storage Temperature | -4 to 158°F (-20 to 70°C [no condensation]) | |
| Interface | USB | |
| Datalogging | 10,000 Measurements | |
| Power Supply | 4 x AA Batteries or AC Adapter | |
| Weight | 360g (0.79 lbs) | |
| Dimensions | W85 x H200 x D40 mm | |
- 5/16″ x 8-5/8″ Stainless Steel Pitot Tube: Model 6700-02
- 5/16″ x 12-5/8″ Stainless Steel Pitot Tube: Model 6700-03
- 5/16″ x 18-5/8″ Stainless Steel Pitot Tube: Model 6700-04
- Static Pressure Probe: Model 6700-08
- Pressure Tubing: Model 6700-30
